Getting Started with WingEdit for the Behringer WING: A Complete Setup Guide
If you’re diving into digital mixing with the Behringer WING console, mastering the WingEdit companion software sets you up for a more flexible, efficient workflow. Whether you’re managing live church productions, editing show files at home, or extending your control setup with additional screens, WingEdit acts as a powerful supplement to your main console.
In this article, we will go through the step-by-step process to install, connect, and utilize WingEdit software on a Mac or Windows PC. We’ll also explore how to navigate this digital interface effectively and highlight key features that make this software a must-have for WING users.
What Is WingEdit?
WingEdit is Behringer’s proprietary software designed to extend the functionality of their WING digital mixer. It can operate in several modes:
- Remote live control of the WING console via a computer.
- Offline editing of show/session files without the physical console.
- Synchronization between computer and console for seamless transfer of settings.
- Virtual extension of your console with the option for secondary displays or external USB fader control.
WingEdit is especially valuable in environments like houses of worship, where flexibility, remote control, and editing consistency are vital.
What You Need:
- Behringer WING (full-size, compact, or WING rack)
- Windows PC or Mac (example used: Mac Mini)
- Local area network (wired or Wi-Fi for the PC and wired for the console)
- Ethernet cable (for WING connection)
- Router/DHCP server
- WingEdit software (downloadable from Behringer’s official website)
STEP 1: Connecting the Behringer WING to the Network
Although WingEdit offers USB connection options, we recommend using a network (Ethernet) connection to keep the USB ports free for audio interfaces or external effects. Here’s how to get your console connected to your network:
Set Up Networking on the WING
- Plug a standard Ethernet cable into the “Control” port on the back of the WING console.
- Connect the other end of the Ethernet cable into your router or network switch.
- On the WING console:
- Tap the Setup button.
- Navigate to the “Remote” tab.
- On the right side, find the Network section.
- Set IP Mode to DHCP to automatically fetch an IP address from your router. This is ideal for most users.
- Once assigned, you’ll see an IP address (e.g., 192.168.1.164). Make a note of this if needed.
NOTE: If you are more experienced in networking or require a fixed IP for routing purposes, you may opt to choose a Static IP. However, this requires knowledge of your network’s structure to avoid IP conflicts.
STEP 2: Installing WingEdit on Your Computer
Now that your WING is online, the next step is to get WingEdit running on your Mac or PC.
Download and Install the Software
- Go to behringer.com.
- Navigate to the Downloads section.
- Apply the following filters:
- Category: Mixers → Digital Mixers → WING
- Product: Choose appropriate version (e.g., Full-Size WING)
- Type: Software
- Platform: Select either Mac or Windows
- Download the latest version of the WingEdit software (currently 3.3.1 as of Dec 2023).
- Run the installer and follow on-screen instructions to complete installation.
STEP 3: Connect WingEdit to Your Console
Once installed, launch the WingEdit software.
- Open the application. The connection status (top-center) will initially show as disconnected.
- Click the Rescan button to search the network for available WING consoles.
- Your WING should appear under the Console section on the left panel.
If not detected automatically, you can manually enter the IP address you noted earlier (e.g., 192.168.1.164) and click Scan.
- Once recognized, click Connect.
- A dialog will appear asking how you want to synchronize settings:
- Mixer → PC: Pull the live console’s settings into the computer. Recommended if you’re just starting your session.
- PC → Mixer: Push previously saved or edited show files from your PC to the console.
- Choose the appropriate direction and begin the sync.
You can also enable:
- Auto Connect: Automatically reconnect if dropped.
- Auto Synchronize: Keeps the two systems continuously synced based on your sync direction.
STEP 4: Navigating the WingEdit Interface
WingEdit mirrors the WING console layout and adds extra management features. Here’s a breakdown of what you’ll find:
Channel Control
- Adjust faders, trim, phantom power, EQ, gating, compression, inserts, and sends.
- Moving a fader in WingEdit mirrors physical fader movement on the console.
- Real-time mix control from your PC or touchscreen computer.
Mixer View
- See an overview of all 16 channels on the current layer.
- Great for fast assessment of levels and quick changes.
Effects Rack
- Full management of FX slots and routing.
Meters & Routing
- Monitor input/output levels.
- Change channel routing and patching.
Setup and Library
- Configure global WING settings (limited compared to onboard UI).
- Access and manage saved presets, snapshots, or session files.
Understanding Section Views
One of the key features of WingEdit is its ability to operate independently from the physical layout of the WING console.
Section Types:
- Left / Center / Right: These replicate the physical WING fader banks and mirror exact layout.
- WingEdit Section: A virtual-only control layer that’s independent from the hardware. Useful as an external control interface or touchscreen fader set.
Example: You can assign different fader arrangements in WingEdit without changing the layout on the physical console—perfect for a separate fader control surface or rehearsal playback rig.
Bonus Tip: Use WingEdit as a Subcontroller
WingEdit doesn’t just offer remote screen mirroring. It can operate as a full control surface when connected to USB fader banks (like the Behringer X-Touch or other MIDI controllers) for additional physical controls apart from the main mixer.
If you have a Mac or PC in your FOH rack, or a touchscreen computer at your streaming station, WingEdit gives you full fader access, parameter controls, and layers without reaching for the mixer. That’s an excellent workflow boost for multi-position operations in a church or worship tech setup.
Summary
WingEdit significantly extends the capabilities of the Behringer WING digital mixer. Whether you’re working onsite or offsite, it enables:
- Real-time remote mixer control.
- Offline show file editing and syncing.
- Multiple control surfaces via USB or touchscreen.
- Customizable channel layers and workflows.
Combined with a solid network connection and basic IP configuration, it becomes a powerful tool for worship tech teams to efficiently maintain and operate their systems.
